PRODUCTS - Magnasite Ramming Mass

Brand Name	MgO	SiO2	Fe2O3	Setting	Grading	Sintering	Application	Application Area
	(%)	(%)	(%)		(mm)	Temp. ('C)	Temp. ('C)
	Min.	Max.	Max			Min.	Max.
SR M-95	94	1.5	-	Chemical	0-5	1550	1750	Tap Hole of BOF
SR Hearth-1	85	5	6	Chemical	0-8	1400	1750	Dry Ramming Mass for EAF bottom
SR Hearth-II	80	1.5	6	Chemical	0-8	1400	1750	Dry Ramming Mass for EAF bottom
SR M-90	90	5	-	Chemical	0-5	1550	1750	Dry Ramming Mass for EAF & other application
SR M-84	83	8.5	-	Chemical	0-5	1550	1750	Wet Ramming Mass for EAF
SR M-84(SPL)	83	7.5	-	do	0-5	1550	1750	do
SR-L(C)X	70	Cr2O3:8	-	do	0-5	800	1750	Dry Ramming mass for
		(Min.)						Induction furnace melting
								mild steel & alloy steel
SR coat-M	88	-	-	do	0-0-5	-	-	Protective coating of coils of
								high frequency induction furnace

BASIC SPRAYING MIXES

Brand Name	MgO	SiO2	Fe2O3	Setting	Grading	Sintering	Appln.	PLC	B.D.	PLC	Application Area
	(%)	(%)	(%)	(mm)	Temp	Temp	(%)	(gm/cc)	(gm/cc)	after firing
						(OC)	(OC)	at 1525'C	after drying	at 1525'C
								3 Hrs.	at 110'C	3 Hrs.
	Min.	Max.	Max			Min.	Max.	Max.	Max.	Max.
SRlite T/87-70	66	25	5.5	Chemical	0-0.5	750	1600	-3.0	1.80	1.85	Spraying of bottom and
											walls of tundish
SRlite T/87-80	78	14	5.0	do	0-0.5	750	1650	-5.0	1.85	1.90	do
SRlite T/87-90	85	7	3.0	do	0-0.5	750	1650	-5.0	1.85	1.90	do
SR VRT-80	78	14	5.0	do	0-1	750	1650	-1.5	2.30	2.35	Dry vibratable mix for bottom
											and wall of tundish
Grading:- 95% Min. will pass through the maximum grain size mentioned.
